System Actuation Methods in Wet Chemical Fire Suppression: Automatic vs. Manual

In commercial kitchens, fires escalate in seconds. Actuation is the moment your system starts—releasing agent and shutting down heat so flames stop growing. Below you’ll find a quick, visual tour of how automatic detection and manual pull work together, what shutoff interlocks do, and where real-world placement rules come in.

Detection: Heat detectors or fusible links above appliances/inside ducts sense high temperature and trip the release mechanism.
Discharge: Expellant gas (often nitrogen) drives the wet chemical to nozzles; agent blankets hot oils and cools surfaces to prevent re-ignition.
Signals & shutdowns: Alarms/indicators operate and interlocks cut power and fuel to cooking equipment (see “Shutoff & Interlocks”).
💡
Why automatic? It responds even if nobody sees the fire—critical for fast-growing grease fires behind or above the cooking line.

Manual actuation is your human-override: the cook or staff member pulls a dedicated station in the path of egress to instantly fire the system. Typical rules of thumb:

  • Locate in the egress route, generally 10–20 ft from the hazard—close enough to reach, far enough to avoid the fire plume.
  • Mounting height commonly 42–48 in to the operable part (some jurisdictions permit up to 60 in under NFPA 96—confirm with the AHJ).
  • Pull force ≤ 40 lbf (178 N) and stroke ≤ 14 in (356 mm) so it’s usable under stress.
🧯
Good practice: Use simple graphics on the station and train staff quarterly—people remember pictures better than text in an emergency.

Actuation isn’t only about spraying agent—it removes heat from the equation. On activation (auto or manual), interlocks:

  • Shut off all fuel and electric power that produces heat to protected appliances (and any unprotected appliances under the same hood).
  • Require a manual reset before fuel/power can be restored.
  • Exceptions: Steam from an external source and solid-fuel cooking operations are handled differently under NFPA 96.

This prevents re-ignition while the saponified foam blanket cools the oil and surfaces.

AspectAutomatic ActuationManual Actuation
How it startsSensors/fusible links trigger releaseStaff pull a station/switch
SpeedImmediate when set correctlyFast, but human-dependent
Best forUnattended or hidden firesVisible flare-ups, backup to auto
Code intentNFPA 17A requires both methods, independent of each other, for redundancy.

Jargon, De-mystified 🧠

Myth vs. Fact 🔎

Myth: “If sprinklers exist, the hood system can be manual-only.”
Fact: Hood systems need both automatic and manual methods—separate and independent.
Myth: “After discharge, appliances can auto-restart once smoke clears.”
Fact: Shutoffs require manual reset to prevent re-ignition.
Myth: “Any pull station height is fine if it’s labeled.”
Fact: Typical mounting is 42–48 in; some allow up to 60 in—confirm with the AHJ.

Tip: Tap/click a card to flip.

Fast AHJ Site-Walk Checklist ✅

Standards & notes (editor-friendly):
  • NFPA 17A (wet chemical): automatic and manual actuation required; independent means; typical manual pull ≤40 lbf, ≤14 in travel; locate on egress path. (Verify edition adopted by AHJ.)
  • NFPA 96 (ventilation/fire protection): on actuation, shut off all fuel/electric heat to equipment under the hood; manual reset required; exceptions for steam & solid-fuel. Typical manual station height guidance varies by jurisdiction.
Always follow the specific manufacturer’s listed manual for the installed system.
